For quality engineers and production managers working with large assemblies – aircraft wings, automotive body‑in‑white, or robotic work cells – traditional fixed CMMs or manual gauges simply cannot reach. Today, MSK CNC Tools announces its new portable laser tracker, a high‑accuracy 3D laser tracker engineered for on‑site, large‑scale dimensional measurement.
This laser tracker system combines laser interferometric ranging, photoelectric detection, and precision mechanics into a compact, transportable unit. Whether you need to align machine tools, verify assembly tolerances, reverse‑engineer large parts, or calibrate industrial robots, MSK’s portable laser tracker delivers reliable, real‑time 3D coordinates with micrometer‑level precision – all the way out to a working radius of tens of meters.
“Traditional CMMs are powerful but fixed. Our new portable laser tracker brings the lab to the part – not the other way around,” said an MSK product manager. “As a true 3D laser tracker, it’s built for the factory floor, outdoor job sites, and every environment in between.”
Why the Portable Laser Tracker Outperforms Traditional Measurement Methods
Unlike articulated arms or total stations, this 3d laser tracker uses a laser beam to continuously track a target mirror held against the part. It measures both angles (horizontal and vertical) and distance simultaneously, creating a spherical coordinate system. The result is real‑time, high‑precision 3D coordinates without line‑of‑sight issues common with photogrammetry.
Key advantages that set this portable laser tracker apart:
- Large working volume – measures components up to tens of meters in size, from aircraft fuselages to wind turbine hubs
- True portability – the integrated tracking head is light enough for one person to carry; the carbon fiber tripod and accessory cases allow rapid setup anywhere
- High data output speed – captures thousands of points per second, enabling dynamic measurements of moving objects (e.g., robot arm paths)
- Combined absolute & interferometric ranging – ensures reliable measurement even if the laser beam is temporarily blocked and then restored
- Automatic target re‑acquisition – if the beam is interrupted, the integrated camera quickly finds and re‑locks the target ball, minimising downtime
Engineered for Real‑World Industrial Environments
The new laser tracker is built to withstand the rigours of production floors and outdoor sites:
- Integrated weather station – continuously monitors temperature, air pressure, and humidity, compensating for environmental effects on laser accuracy – no external sensors to carry or forget
- Sealed protection – rated against dust and splashes, keeping optics clean even in foundries or composite shops
- Stable tripod design – carbon fibre legs absorb vibration, and a built‑in bubble level simplifies setup on uneven ground
- Wireless communication – connect via Wi-Fi to a laptop or tablet, eliminating cable trips hazards in busy workshops
Why the Portable Laser Tracker Outperforms Traditional Measurement Methods
Unlike articulated arms or total stations, this 3d laser tracker uses a laser beam to continuously track a target mirror held against the part. It measures both angles (horizontal and vertical) and distance simultaneously, creating a spherical coordinate system. The result is real‑time, high‑precision 3D coordinates without line‑of‑sight issues common with photogrammetry.
Key advantages that set this portable laser tracker apart:
-
Large working volume – measures components up to tens of meters in size, from aircraft fuselages to wind turbine hubs
-
True portability – the integrated tracking head is light enough for one person to carry; the carbon fiber tripod and accessory cases allow rapid setup anywhere
-
High data output speed – captures thousands of points per second, enabling dynamic measurements of moving objects (e.g., robot arm paths)
-
Combined absolute & interferometric ranging – ensures reliable measurement even if the laser beam is temporarily blocked and then restored
-
Automatic target re‑acquisition – if the beam is interrupted, the integrated camera quickly finds and re‑locks the target ball, minimising downtime
Engineered for Real‑World Industrial Environments
The new laser tracker is built to withstand the rigours of production floors and outdoor sites:
-
Integrated weather station – continuously monitors temperature, air pressure, and humidity, compensating for environmental effects on laser accuracy – no external sensors to carry or forget
-
Sealed protection – rated against dust and splashes, keeping optics clean even in foundries or composite shops
-
Stable tripod design – carbon fibre legs absorb vibration, and a built‑in bubble level simplifies setup on uneven ground
-
Wireless communication – connect via Wi-Fi to a laptop or tablet, eliminating cable trips hazards in busy workshops
Applications Across Key Industries
Aerautics & Aerospace
Measure wing spar alignment, fuselage section mating, jig and fixture validation, and engine mount positions. The portable laser tracker allows quality teams to verify assembly accuracy directly on the final assembly line – no need to move large components to a metrology lab.
Automotive Manufacturing
Check body‑in‑white dimensions, verify robot end‑effector paths, align press dies, and measure prototype parts. With its high data rate, this 3d laser tracker can even track a robot’s TCP (tool centre point) in motion, enabling dynamic calibration.
Heavy Machinery & Rail Transit
Align large machine tool beds, measure crane rails, verify bogie frames, and perform reverse engineering of worn parts for remanufacturing. The tracker’s large working volume is ideal for components that are simply too big for any conventional CMM.
Robot Calibration & High‑End Manufacturing
For manufacturers integrating industrial robots, the laser tracker is the gold standard for measuring actual TCP position against programmed paths. The system’s output speed (thousands of points per second) captures robot movement with unprecedented detail, allowing precise compensation.
Shipbuilding & Nuclear Power
Measure propeller shaft alignments, reactor vessel penetrations, and large welded structures. The tracker’s portability means it can be taken directly to the dry dock or containment building.
Built for Accuracy & Repeatability
While actual performance depends on the specific model (MSK offers configurations to meet different needs), this 3d laser tracker is engineered to deliver exceptional angular accuracy and distance measurement stability. It complies with international standards (ISO 10360‑10) and includes a calibration certificate with each unit.
The system also features encoder self‑calibration – the tracker can recalibrate its own angular encoders without external equipment, simplifying on‑site verification when environmental conditions change.
Complete System – Ready to Measure
MSK ships each portable laser tracker as a turnkey solution including:
- Tracking head (integrated controller, laser, and sensors)
- Carbon fibre tripod with transport case
- Multiple target mirrors (1.5” and optional 0.5” SMRs)
- Variety of target mounts (pin, planar, edge, magnetic transfer)
- Calibration rod and tripod for on‑site verification
- High‑performance laptop with pre‑installed software
- All necessary cables, cleaning kit, and documentation
The system is ready for immediate use – simply unpack, set up, and start measuring.
Cost‑Effective Alternative to Premium Brands
MSK offers this laser tracker at a competitive price point without compromising on core capabilities. For businesses that need a reliable portable laser tracker but have been deterred by the high cost of established brands, the MSK system provides an attractive balance of performance and value.
Availability & Contact Information
The new portable laser tracker series is available immediately for global orders. To request a quote, receive a product brochure, or schedule a live online demo:
Email: molly@mskcnctools.com
Phone: 008613602071763
Web: www.mskcnctools.com
MSK welcomes inquiries from aerospace manufacturers, automotive producers, heavy equipment builders, and automation integrators – from single units to fleet deployments.
