2 flutes ball nose end mill

Shape: Ball head type.
Number of flute: 2 flutes.
Coating: (AI, Ti, Cr) N-type multilayer coating.


Product Detail

Product Tags

1

Produced by foreign first-class precision machine, the ball nose end mill can grind the unique spiral edge angle, the large core diameter design improves the rigidity and shock resistance. And the large chip removal space is not easy to accumulate chip, break the knife.
It is sharp and wear-resistant, the chip is smoothly cut, and the milling efficiency is improved.

Type Ball nose surface
Workpiece material Ordinary steel / high hardness steel~HRC55 / stainless steel / cast iron / titanium / copper
Flutes Number 2
Coating Customzied
Brand MSK
Flute length 2-24
Shank diameter(d)(mm) 4-12
Flute Length 2-24

Feature:
Titanium aluminum nitride (AlTiN or TiAlN) coatings are slippery enough to help keep chips moving, especially if you aren’t using coolant. This coating is often used on carbide tooling.
2.If you’re using high-speed steel (HSS) tooling, look for coatings like titanium carbo-nitride (TiCN). That way you get the lubricity needed for aluminum, but you can spend a little less cash than on carbide.

Flute Diameter D1 Flute Length L1 Shank diameterd Length L
1 2 4 50
1.5 3 4 50
2 4 4 50
2.5 5 4 50
3 6 3 50
3 6 4 50
3.5 7 4 50
4 8 4 50
5 10 5 50
5 10 6 50
6 12 6 50
8 16 8 60
4 8 4 75
6 10 6 75
6 10 6 75
8 16 8 75
10 20 10 75
12 24 12 75
4 8 4 100
6 12 6 100
8 16 8 100
10 20 10 100
12 24 12 100
6 12 6 150
8 16 8 150
10 20 10 150
12 24 12 150

Use:

cxuytiu
Aviation Manufacturing

nbviytuiMachine Production

jhfkjkfCar manufacturer

bvcityui
Mold making

cvuityo
Electrical Manufacturing

gfdsLathe processing
